Starting mass and hardware capabilities retain the manufacturer's source conditions. Unlisted measurements remain unknown; no independent performance or retailer stock is established.
Exact configuration: UK manufacturer order code · ra13250_reg_01
26 specifications in 8 groups. Values are manufacturer specifications unless a row says “Measured result” or “Calculated from cited specifications”. 9 rows repeat listed facts in the manufacturer’s own wording, kept under “Manufacturer wording”.
Processor, graphics & memory
3 items
Selected processor configuration
Intel® Core™ Ultra 5 135U (12 cores, up to 4.4 GHz, 15 W)Source
Selected installed memory
16 GB: 2 x 8 GB, LPDDR5x, up to 6400 MT/s (onboard)Source
Selected installed memory capacity
16 GB
Literal installed-memory capacity; not maximum memory support.
16 GB: 2 x 8 GB, LPDDR5x, up to 6400 MT/s (onboard)
1 GB means 1 billion bytes and TB equals 1 trillion bytes; significant system memory may be used to support graphics, depending on system memory size and other factors.
1 headset (headphone and microphone combo) port 1 USB 3.2 Gen 1 (5 Gbps) port 1 USB 3.2 Gen 1 port with PowerShare 1 Thunderbolt™ 4/USB 4 Type-C® with Power Delivery 1 Thunderbolt™ 4/USB 4 2 Type-C® with Power Delivery port (optional) 1 HDMI 2.1 port 1 RS-232 Serial port 1 RJ45 Ethernet port, 1GbE 1 Optional I/O bay (Choose from: RJ45 (1 Gbps) Ethernet port/USB 3.2 Type-A port/Serial port/Fischer USB port)Source
Selected wireless configuration
Intel® Wi-Fi 6E AX211 wireless card, 2x2, 802.11ax, Bluetooth® 5.3Source
1 headset (headphone and microphone combo) port 1 USB 3.2 Gen 1 (5 Gbps) port 1 USB 3.2 Gen 1 port with PowerShare 1 Thunderbolt™ 4/USB 4 Type-C® with Power Delivery 1 Thunderbolt™ 4/USB 4 2 Type-C® with Power Delivery port (optional) 1 HDMI 2.1 port 1 RS-232 Serial port 1 RJ45 Ethernet port, 1GbE 1 Optional I/O bay (Choose from: RJ45 (1 Gbps) Ethernet port/USB 3.2 Type-A port/Serial port/Fischer USB port)
Intel® Wi-Fi 6E AX211 wireless card, 2x2, 802.11ax, Bluetooth® 5.3
Wi-Fi 7 certified products will roll out in accordance with the Wi-Fi Alliance certification schedule throughout 2024. WiFi 7 requires the latest Wi-Fi Alliance certification, Windows HLK certified device driver, hardware update, supported Windows OS version and compatible router. Wi-Fi 7/ 6E connectivity (6 GHz) with Windows 11 is limited and will leverage prior generation of Wi-Fi 6E/ Wi-Fi 6 speeds until drivers are available and hardware adoption increases. Ubuntu OS will not support Wi-Fi 7 and will operate on WiFi 6E/6 speeds when configured for WiFi 7. Router requires a separate purchase. Wi-Fi 7/ 6E (6 GHz) connectivity is only available in select locations. Check availability with your service provider. The Bluetooth wireless card version may vary depending on the operating system that is installed on your computer.
Original manufacturer dimension/mass row: Height (rear): 36.50 mm (1.43 in.) Height (front): 36.50 mm (1.43 in.) Width: 324 mm (12.75 in.) Depth: 220 mm (8.66 in.) Weight: 2.40 kg (5.29 lb). A starting or minimum mass is not independently measured exact-unit weight; ambiguous multiple masses remain unknown.
